Drill Diameter:

HTW-NTW-BTW

Drill Depth:

900-1500-1800(M)

Rated Pressure:

28(MPA)

Rated Flow Rate:

400(L/min)

Cooling Method:

Air Cooling + Water Cooling

Engine:

Cummins, Turbocharged

Engine Rated Speed:

2400(RPM)

Engine Rated Power:

194  (KW)

Power Head Torque：

1500-5000(N.M)

Power Head Speed：

1300(RPM)

Power Head Feed Stroke

3500(MM)

Tower Type:

Touchdown Integral Tower

Tower Drilling Angle:

45-90(°)

Tower Lifting Force:

45(T)

Tower Feed Force:

20(T)

Core Recovery Winch Lifting Force:

1200(KG)

Core Recovery Winch Speed:

100-300(RPM)

Core Recovery Wire Rope Diameter:

6(MM)

Core Recovery Wire Rope Capacity:

1300(M)

Main Winch Lifting Force:

5(T)

Main Winch Speed:

0-45(RPM)

Main Winch Wire Rope Diameter:

16(MM)

Main Winch Wire Rope Capacity:

50(M)

Travel Type:

Manual + Remote Control

Travel Speed:

3.5(KMH)

Single Machine Climbing Angle:

45(°)

Mud Pump Flow Rate:

90-180(Lmin)

Mud Pump Pressure:

4-7(MPA)

Generator Type:

Variable Frequency Brushless Maintenance-Free

Engine Power and Voltage:

11KW 220V 380V

Transport Dimensions:

6000*2200*2400(MM)

Total Machine Weight：

10.5(T)
