Drilling ability

Caliber:

50-200mm Hydraulic double clamp,

Depth

500m

Hydraulic system

Rated pressure::

28MPa

Rated flow:

280L/min

Heat dissipation mode:

air cooling + water cooling

Motor

Brand:

yuchai（Turbo charged）

Rated speed::

2400rpm

Rated power:

92KW

Power head

MAXIMUM TORQUE:5

5000N.M

Maximum speed:

80- 1200 (RPM)

Stroke:

6600mm

Drill Tower

Type:

Chain compound tower, 6.6m

Drilling angle: :

55-90(°)

Lifting force:

15T

Feed force:

8T

Wireline Hoist

LIFTING FORCE: :

500kg

Rotational speed:

0-300rpm

WIRE ROPE DIAMETER:

6mm

Capacity:

600m

Main hoist

lifting force:

5T

WIRE ROPE DIAMETER:

16mm

Rotational speed:

0-40rpm

Capacity:

45m

Walk

Type:

manual + remote control

WALKING SPEED:

2.5km/h rubber track

Climbing angle of single machine:

35( °)

Hydraulic mud pump

Flow rate:

250L/min

Pressure:

8MPA

DRILL RING SIZE  ：

5.5m*1.8m*2. 1m

DRILL RING WEIGHT:

5500kgs
